INTRODUCTION
1.4

System Components

The Liquidew I.S. Process Moisture Analyzer consists of:
• the sensor assembly
• the control unit
Sensor Assembly
(Up to four channels can have any combination of Liquidew I.S. and Promet I.S.*)
* Promet I.S. is a sister product of the Liquidew I.S. and is used for moisture in gas
measurement
4
c
b
a
a Temperature transmitter
b Sensor block
c Dew-point transmitter
d User interface
e Electrical connections - to hazardous area
f Electrical connections - non-hazardous
Major Components of the Liquidew I.S.
Figure 3
Liquidew I.S. User's Manual
Control Unit
