OPERATION
2.7.9
Light Guide
The light guide is fitted to the right-hand side of the lower surface and has a red and
green LED to display the current status.
•
Green On – indicates instrument power is on.
•
Red LED flashing – indicates when external compensation input or external
sensor is out of range (if either is selected to ON). Out of range is <3.6
mA or >21 mA (see Status Message Table in Section 2.5.1).
•
Red LED on – indicates an internal sensor error or instrument cell
temperature not yet stabilized (see Status Message Table in Section 2.5.1)
These have been designed to follow the NAMUR NE44 standard.
26
XTP501 & XTC501 User's Manual
99976 Issue 1.1, May 2020
