XTP501 & XTC501 User's Manual
Common Features and Specifications
Electrical Specifications
Display Type
Display Resolution
Analog Inputs
Analog Outputs
Output Ranges
Alarms
Digital Communications
Power Supply
Electrical connections
Operating Conditions
Ambient Temperature
Atmospheric Pressure
Ambient Relative Humidity
Mechanical Specification
Warm-Up Time
Stabilization Time
Dimensions
Weight
Wetted Materials
O-Ring Materials
Gas Connection
Ingress Protection
Michell Instruments
Backlit LCD (GP1 model only)
0.01%
0.1% for XTP with suppressed zero ranges or XTC ranges
> 10%
2 off 4–20 mA inputs
One for an external sensor that can be displayed on the
screen
One to act as an active compensation for the process
conditions
2 off 4–20 mA outputs (powered with 24V excitation
voltage)
Primary range is set to the calibrated range of the
instrument
The second is user selectable 0–100%
2 off single pole changeover (SPCO) relays for O
concentration (250 V, 5 A max)
Modbus RTU over RS485 Protocol
24 V DC; 1.5 A max – Mating connector supplied
Analyzer is supplied with required mating connectors.
5 to +45 °C (+41 to +113°F)
750 mbar to 1250 mbar
0 to 95% rh (non-condensing)
< 25 minutes
5 minutes
260 x 180 x 128mm (10.24 x 7.09 x 5.04") (h x w x d)
Approx. 3kg (6.6lbs)
316 & 430F stainless steel, borosilicate glass, platinum, 3M
2216 plus O-ring
Viton
1/8" Swagelok
IP55
APPENDIX A
