UNIT DATA

4.2.4 Additional precharging resistor at master-slave operation

The external precharging resistor is required from housing size 29. The re-
sistor is used for additional energy input and limitation of the charging cur-
rent. The external resistor is switched into phase L1 at the precharge input
(=>
filter").
Material number
0090013-0048

4.3 Dimensions and weights

The COMBIVERT F5-AIC have identical housings with the COMBIVERT F5 drive con-
verters. Dimensions, weights and terminal descriptions can be found in the following
instruction manuals:
Table 13:
„Circuit example for the master-slave operation with AIC/LCL filter and common mode
Resistance R
5.8 Ω
Size
14
16
18
20, 22
24, 26, 27
28, 29, 30, 33, 34, 38
Dimensions and weights
The instruction manuals can be found in the specified links or under
Power
v
165 W
Housing
E
G
H
R
U
P
www.keb.de/de/service/downloads.
Voltage
1100 V
Instruction manual
Housing E
Housing G
Housing H
Housing R
Housing U
Housing P
