Brainlab Buzz Site Planning Manual page 62

Digital OR Computer For Barco Integration Connections
Digital OR Computer For Barco Integration Output Formats
Displays
Displays 1-8
Digital OR Computer For Barco Integration Input Connectors
Digital OR Computer For Barco Integration has no direct video inputs. It offers connectivity to
the Barco Nexxis video routing network:
• Imaging Input: Barco Nexxis
• Connector: QSFP+
• Signal Type: Various
• Impedance: n/a (fiber)
Digital OR Computer For Barco Integration Output Connectors
Displays
Displays 1-8
Compatible Cables and Connectors
Port
Hospital net-
Feature Panel
DisplayPort
Barco Nexxis
Video QSFP+
62
Connector
Display Port
Connector
Display Port
Example
USB
work
LAN
Signal Type
DisplayPort 1.4
Signal Type
DisplayPort 1.4, Dis-
playPort++
Handling
USB ports for connecting USB 2.0 and 3.0 devices for
patient data transfer.
NOTE: Do not connect network adapters or USB ex-
tension cables to the USB ports.
Galvanic isolated Ethernet port for connecting to Hospi-
tal network.
There is a latch at the bottom which locks when plug-
ged into the port. When removing the connector, press
the latch, then pull plug out.
Connect DisplayPort display using DisplayPort 1.2 ca-
ble (max. 5m for 1920 x 1080/60 Hz and max 3.6 m for
3840 x 2160/30 Hz/60 Hz).
Fiber LAN cable with duplex LC-connector
Insert QSFP+ module into QSFP+ cage on computer.
Site Planning Manual Rev. 1.1 Buzz Ver. 2.0
Format
Format FullHD, UHD1,
4k, and up to HDR
5120 x 2880 at 60Hz
(30-bit color)
Impedance (Ohm)
100
