Brainlab Buzz Site Planning Manual page 12

Buzz Configurations
2. Flexible Setup: Computer mounted up to 2.5 m away from the display:
3. Long Distance Setup: Computer mounted up to 100 m away from the (Touch) display.
No.
①
②
③
④
⑤
Buzz In-Wall
Buzz In-Wall comprises a touch display integrated in the wall. The computer is separate and may
be located up to 100 m away (e.g., in a control room rack).
Alternatively, you may replace the Buzz computer with the Digital OR Computer For Barco
Integration.
No.
①
②
③
④
12
⑤
Component
User panel (behind cover)
Computer (including cover)
Touch display
Feature panel
Connection panel cover
① ②
Component
Computer
Touch display
Feature panel
Digital OR Computer For Barco Integration
Figure 2
③
Figure 3
Site Planning Manual Rev. 1.1 Buzz Ver. 2.0
④
