PLANNING AND SITE PREPARATION
Buzz In-Wall Ventilation Openings
Ventilation openings are located as marked below.
No.
①
②
NOTE: There are no exposed ventilation openings on the In-Wall touch display.
NOTE: The computer must be installed on the bottom/base plate to not block the ventilation
openings.
Buzz In-Wall Mounting Frame
Ventilation openings are located as marked below.
NOTE: There are no exposed ventilation openings on the In-Wall Touch Display.
Site Planning Manual Rev. 1.1 Buzz Ver. 2.0
①
Component
Computer connection panel
Computer user panel
②
Figure 29
Figure 30
53
