Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7, CN8
CN9
CN10
CN11
CN12
CN13, CN14
CN15, CN16
CN17
CN18
CN19
CN20
ATX1
BAT1
SCN1
SCN2
SCN3
SDIMM1
12
Processor Family 3.5" Board
Description
Front Panel Connector
SMBus Connector
HDMI Connector
DisplayPort Connector
Inverter Connector
LVDS Connector
Ethernet Port 1 and 2
Ethernet Port 3 Wafer Connector
USB 3.0 Port
USB 3.0/USB2.0 Port
USB 2.0 Wafer Connector
SATA 0 and 1 Ports
SATA 0 and 1 Power Connectors
COM1 Wafer Connector
Fan Connector
Digital I/O Connector
Audio HDA Wafer Connector
ATX Power Connector
CMOS Battery Connector
Full-size PCI-Express Mini Card Connector
SIM Card Wafer Connector
ZIO Expansion Connector
DDR4 SO-DIMM Connector
