  • Page 1 CAPA848 ® ® Intel Celeron Processor N2807 Capa Board User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.

  • Page 3: Esd Precautions

     Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. AMI is a trademark of American Megatrend Inc.

  • Page 4: Table Of Contents

    Table of Contents Disclaimers ..................... ii ESD Precautions ................... iii Chapter 1 Introduction ..........1 Features ....................2 Specifications ..................2 Utilities Supported ................3 Chapter 2 Board and Pin Assignments ....5 Board Dimensions and Fixing Holes ..........5 Board Layout ..................
  • Page 5 Chapter 3 Hardware Description ......25 Microprocessors ................25 BIOS ....................25 System Memory ................. 25 I/O Port Address Map ................ 26 Interrupt Controller (IRQ) Map ............28 Memory Map ..................34 Chapter 4 AMI BIOS Setup Utility ......35 Starting ....................
  • Page 6 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

    I/O functions for interactive applications and various embedded computing solutions. The CAPA848 comes with one 204-pin unbuffered SO-DIMM socket for single channel DDR3L 1333MHz memory, maximum memory capacity up to 8GB. There is one Gigabit/Fast Ethernet port, one SATA port with transfer rate up to 3Gb/s, four USB 2.0 high speed compliant, and...

  • Page 8: Features

    CAPA848 Capa Board Features ® ®  Intel Celeron dual core N2807 (1.58GHz)  1 DDR3L SO-DIMM supports up to 8 GB memory capacity  4 USB 2.0 ports  4 COM ports  2 PCI-Express Mini Card  +12V only DC-in supported ...

  • Page 9: Utilities Supported

    CAPA848 Capa Board  Watchdog Timer  1~255 seconds or minutes; up to 255 levels.  Ethernet ®  One RJ-45 LAN port: Intel i211AT supports 1000/100/10Mbps Gigabit/Fast Ethernet with Wake-on-LAN and PXE Boot ROM.  Audio  HD audio compliant with Realtek ALC662.
  • Page 10 CAPA848 Capa Board This page is intentionally left blank. Introduction...

  • Page 11: Board And Pin Assignments

    CAPA848 Capa Board Chapter 2 Board and Pin Assignments Board Dimensions and Fixing Holes Top View Board and Pin Assignments...
  • Page 12 CAPA848 Capa Board Bottom View Side View Board and Pin Assignments...

  • Page 13: Board Layout

    CAPA848 Capa Board Board Layout Top View Side View Board and Pin Assignments...
  • Page 14 CAPA848 Capa Board Bottom View Board and Pin Assignments...

  • Page 15: Jumper Settings

    And remove jumper clip from 2 jumper pins to open. Below illustration shows how to set up jumper. Properly configure jumper settings on the CAPA848 to meet your application purpose. Below you can find a summary table of all jumpers and onboard default settings.

  • Page 16: Lvds Voltage Selection (Jp1 And Jp6)

    CAPA848 Capa Board 2.3.1 LVDS Voltage Selection (JP1 and JP6) The board supports voltage selection for flat panel displays. Use these jumpers to set LVDS connector (CN3) pin 1~6 VCCM to +3.3V, +5V or +12V. To prevent hardware damage, before connecting please make sure that input voltage of flat panel is correct.

  • Page 17: Connectors

    CAPA848 Capa Board Connectors Signals go to other parts of the system through connectors. Loose or improper connection might cause problems, please make sure all connectors are properly and firmly connected. Here is a summary table of connectors on the hardware.

  • Page 18: Front Panel Connector (Cn1)

    CAPA848 Capa Board 2.4.1 Front Panel Connector (CN1) Signal PWRLED+ EXT SPK- N.C. Buzzer PWRLED- N.C. N.C. EXT SPK+ PWRSW- PWRSW+ HW RST- HW RST+ HDDLED- HDDLED+ Power LED Pin 1 connects anode(+) of LED and pin 5 connects cathode(-) of LED. The power LED lights up when the system is powered on.

  • Page 19: Inverter Connector (Cn2)

    CAPA848 Capa Board 2.4.2 Inverter Connector (CN2) This is a DF13-8S-1.25C 8-pin connector for inverter. We strongly recommend you to use the matching DF13-8S-1.25C connector to avoid malfunction. Signal VBL1 (+12V level) VBL1 (+12V level) VBL2 (+5V level) VBL_ENABLE VBL Brightness Control 2.4.3...
  • Page 20 CAPA848 Capa Board 24-bit single channel 18-bit dual channel Pin Signal Pin Signal Pin Signal Pin Signal 1 VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM N.C. N.C. N.C. N.C. 10 GND 10 GND 11 N.C.

  • Page 21: Audio Connector (Cn4)

    CAPA848 Capa Board 2.4.4 Audio Connector (CN4) Signal Signal MIC_IN LINE_IN_L LINE_IN_R AUDIO_OUT_L AUDIO_OUT_R 2.4.5 Digital I/O Port Connector (CN5) The board is equipped with an 8-channel (3 inputs and 5 outputs) digital I/O connector that meets requirements for a system customary automation control. The digital I/O can be configured to control cash drawers and sense warning signals from an Uninterrupted Power System (UPS), or perform store security control.

  • Page 22: Usb Wafer Connector (Cn9)

    CAPA848 Capa Board 2.4.8 USB Wafer Connector (CN9) This 2x5 pin wafer is a Universal Serial Bus (USB) connector for installing versatile USB 2.0 compliant interface peripherals. The CN9 carries USB port 2 and 3. Signal Signal USB VCC USB VCC...

  • Page 23: Com3 And Com4 Connector (Cn11)

    CAPA848 Capa Board 2.4.10 COM3 and COM4 Connector (CN11) This is a 2x10-pin pitch=1.27mm wafer connector for COM3 and COM4. The pin assignments are listed in table below. Signal Signal DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 N.C. DCD4 DSR4...

  • Page 24: Power Connector (Atx1)

    CAPA848 Capa Board 2.4.13 Power Connector (ATX1) Steady and sufficient power can be supplied to all components on the board by connecting the power connector. Please make sure all components and devices are properly installed before connecting the power connector.

  • Page 25: Usb Port (Usb1)

    CAPA848 Capa Board 2.4.15 USB Port (USB1) The USB1 is a Universal Serial Bus (compliant with USB 2.0 (480Mbps)) connector on the rear I/O. It is commonly used for installing USB peripherals such as keyboard, mouse, scanner, etc. Signal Signal...

  • Page 26: Com2 Connector (Com2)

    CAPA848 Capa Board 2.4.18 COM2 Connector (COM2) This connector 2x5-pin wafer connector. assignments RS-232/RS-422/RS-485 are listed in table below. If you need COM2 port to support RS-422 or RS-485, please refer to BIOS setting in section 4.4. RS-232 RS-422 RS-485...

  • Page 27: Half-Size Pci-Express Mini Card Connector (Scn1)

    CAPA848 Capa Board 2.4.20 Half-size PCI-Express Mini Card Connector (SCN1) The SCN1 is a half-size PCI-Express Mini Card connector. It supports the PCI-Express Mini Cards which are applied to either PCI-Express x1 or USB. It complies with PCI-Express Mini Card Spec. V1.2.

  • Page 28: Full-Size Pci-Express Mini Card Connector (Scn2)

    CAPA848 Capa Board 2.4.21 Full-size PCI-Express Mini Card Connector (SCN2) This is a PCI-Express Mini Card connector on the bottom side applying to either PCI-Express or USB 2.0 or SATA (mSATA). It complies with PCI-Express Mini Card Spec. V1.2. It can also support mSATA cards. Please refer to BIOS setting in section 4.4 to...

  • Page 29: Sim Card Socket (Scn3)

    CAPA848 Capa Board 2.4.22 SIM Card Socket (SCN3) This board has SCN3 socket on the bottom side for inserting SIM Card. In order to work properly, the SIM Card must be used together with 3G module which is inserted to SCN1 or SCN2.
  • Page 30 CAPA848 Capa Board This page is intentionally left blank. Board and Pin Assignments...

  • Page 31: Chapter 3 Hardware Description

    Make sure all correct settings are arranged for your installed microprocessor to prevent the CPU from damages. BIOS The CAPA848 uses AMI Plug and Play BIOS with a single 16Mbit SPI Flash. System Memory The CAPA848 supports one 204-pin DDR3L SO-DIMM socket for a maximum memory of 8GB DDR3L SDRAMs.

  • Page 32: I/O Port Address Map

    CAPA848 Capa Board I/O Port Address Map ® ® The Intel Celeron N2807 processor communicate via I/O ports. Hardware Description...
  • Page 33 CAPA848 Capa Board Hardware Description...

  • Page 34: Interrupt Controller (Irq) Map

    CAPA848 Capa Board Interrupt Controller (IRQ) Map The interrupt controller (IRQ) mapping list is shown as follows: Hardware Description...
  • Page 35 CAPA848 Capa Board Hardware Description...
  • Page 36 CAPA848 Capa Board Hardware Description...
  • Page 37 CAPA848 Capa Board Hardware Description...
  • Page 38 CAPA848 Capa Board Hardware Description...
  • Page 39 CAPA848 Capa Board Hardware Description...

  • Page 40: Memory Map

    CAPA848 Capa Board Memory Map The memory mapping list is shown as follows: Hardware Description...

  • Page 41: Ami Bios Setup Utility

    CAPA848 Capa Board Chapter 4 AMI BIOS Setup Utility The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a flash chip to save the setup information whenever the power is turned off. This chapter provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.
  • Page 42 CAPA848 Capa Board Hot Keys Description  Left/Right The Left and Right <Arrow> keys allow you to select a setup screen. The Up and Down <Arrow> keys allow you to select a setup screen or  Up/Down sub-screen. The Plus and Minus <Arrow> keys allow you to change the field value of a +...

  • Page 43: Main Menu

    CAPA848 Capa Board Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 44: Advanced Menu

    CAPA848 Capa Board Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 45 CAPA848 Capa Board  ACPI Settings You can use this screen to select options for the ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 46 CAPA848 Capa Board  NCT6106D Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 47 CAPA848 Capa Board  Serial Port 1 (COM1) Serial Port Enable or disable serial port 1. The optimal setting for base I/O address is 3F8h and for interrupt request address is IRQ4. COM Port Type Use this item to set RS-232/RS-422/RS-485 mode.
  • Page 48 CAPA848 Capa Board  NCT6106D HW Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, cooling fan speed in RPM and system voltages (VCORE, +3.3V, +12V and +5V). AMI BIOS Setup Utility...
  • Page 49 CAPA848 Capa Board  CPU Configuration This screen shows the CPU Configuration. Socket 0 CPU Information This item is for CPU information. AMI BIOS Setup Utility...
  • Page 50 CAPA848 Capa Board  Socket 0 CPU Information Intel Virtualization Technology Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine Mode) can utilize the additional hardware capabilities. It allows a platform to run multiple operating systems and applications independently, hence enabling a computer system to work as several virtual systems.
  • Page 51 CAPA848 Capa Board  IDE Configuration In the IDE Configuration menu, you can see the currently installed hardware in the SATA ports. During system boot up, the BIOS automatically detects the presence of SATA devices. Serial-ATA (SATA) Enable or disable the SATA Controller feature. The default is Enabled.
  • Page 52 CAPA848 Capa Board SATA Switch This option appears only after SATA Port 1 is enabled. The default is PCIe. If you intend to insert mSATA card to SCN2 (see section 2.4.21), please change setting to mSATA. AMI BIOS Setup Utility...
  • Page 53 CAPA848 Capa Board  USB Configuration USB Devices Display all detected USB devices. Legacy USB Support Use this item to enable or disable support for USB device on legacy operating system. The default setting is Enabled. Auto option disables legacy support if no USB devices are connected.

  • Page 54: Chipset Menu

    CAPA848 Capa Board Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► North Bridge ►...
  • Page 55 CAPA848 Capa Board  North Bridge This screen shows system memory information and allows users to configure parameters of North Bridge chipset. LVDS Panel Type Select LVDS panel resolution. AMI BIOS Setup Utility...
  • Page 56 CAPA848 Capa Board  South Bridge This screen allows users to configure parameters of South Bridge chipset. Audio Controller Control detection of the HD Audio device. - Disabled: Audio device will be unconditionally disabled. - Enabled: Audio device will be unconditionally enabled.

  • Page 57: Security Menu

    CAPA848 Capa Board Security Menu The Security menu allows users to change the security settings for the system.  Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled).  User Password This item indicates whether an user password has been set (installed or uninstalled).

  • Page 58: Boot Menu

    CAPA848 Capa Board Boot Menu The Boot menu allows users to change boot options of the system.  Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.

  • Page 59: Save & Exit Menu

    CAPA848 Capa Board Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 60 CAPA848 Capa Board  Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes.  Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.

  • Page 61: Chapter 5 Drivers Installation

    CAPA848 Capa Board Chapter 5 Drivers Installation The device drivers are located on the product information CD that comes with the CAPA848 Series package. The auto-run function of drivers will guide you to install the utilities and device ® drivers under Windows system.
  • Page 62 CAPA848 Capa Board When the following License Agreement screen appears, please click “Yes” to next step. A Readme File Information screen appears to show you the system requirements and installation information. Click “Next” to next step. Drivers Installation...
  • Page 63 CAPA848 Capa Board Please wait while setup processes the following operations. You are suggested to select “Yes, I want to restart this computer now”. Click “Finish” to complete the setup process and reboot. Drivers Installation...

  • Page 64: Installing Graphics Driver

    CAPA848 Capa Board Installing Graphics Driver Run setup program from driver directory in product information CD. Click “Next” to start the installation. Drivers Installation...
  • Page 65 CAPA848 Capa Board ® License Agreement screen appears, please click “Yes” to next step. When Intel A Readme File Information screen appears to show you the system requirements and installation information. Click “Next” to next step. Drivers Installation...
  • Page 66 CAPA848 Capa Board Please wait while setup processes the following operations. When the following screen appears, please click “Next”. Drivers Installation...
  • Page 67 CAPA848 Capa Board You are suggested to select “Yes, I want to restart this computer now”. Click “Finish” to complete the setup process and reboot. Drivers Installation...

  • Page 68: Installing Ethernet Driver

    CAPA848 Capa Board Installing Ethernet Driver Run setup program from driver directory in product information CD. When the following screen appears, please wait while setup prepares the install wizard. Drivers Installation...
  • Page 69 CAPA848 Capa Board Click “Next” to continue. ® When Intel License Agreement screen appears, read it carefully. You are suggested to select “I accept the terms in the license agreement”. Click “Next” to continue. Drivers Installation...
  • Page 70 CAPA848 Capa Board When the following screen appears, please select the program features you want to install. Click “Next” to continue. Now install wizard is ready. Click “Install” to begin installation. Drivers Installation...
  • Page 71 CAPA848 Capa Board Please wait while setup processes the following operations. When driver installation is complete, the following screen appears. Click “Finish” to exit. Drivers Installation...

  • Page 72: Installing Audio Driver

    CAPA848 Capa Board Installing Audio Driver Run setup program from driver directory in product information CD. Click “Next” to continue. Drivers Installation...
  • Page 73 CAPA848 Capa Board You are suggested to select “Yes, I want to restart my computer now”. Click “Finish” to complete setup and reboot. Drivers Installation...

  • Page 74: Installing Trusted Execution Engine

    CAPA848 Capa Board Installing Trusted Execution Engine Run setup program from driver directory in product information CD. When the following screen appears, click “Next” to continue. Drivers Installation...
  • Page 75 CAPA848 Capa Board ® When Intel License Agreement screen appears, read it carefully. You are suggested to select “I accept the terms in the License Agreement”. Click “Next” to continue. Now install wizard is ready. Click “Next” to begin installation.
  • Page 76 CAPA848 Capa Board Please wait while setup processes the following operations. When installation is complete, the following screen appears. Click “Finish” to exit. Drivers Installation...

  • Page 77: Installing Sideband Fabric Device

    CAPA848 Capa Board Installing Sideband Fabric Device Run setup program from driver directory in product information CD. When the following screen appears, click “Next” to continue. Drivers Installation...
  • Page 78 CAPA848 Capa Board ® When Intel License Agreement screen appears, read it carefully. You are suggested to select “I accept the terms in the License Agreement”. Click “Yes” to continue. Please wait while setup processes the following operations. Drivers Installation...
  • Page 79 CAPA848 Capa Board When installation is complete, you are suggested to select “Yes, I want to restart my computer now”. Click “Finish” to complete setup and reboot. Drivers Installation...
  • Page 80 CAPA848 Capa Board This page is intentionally left blank. Drivers Installation...

  • Page 81: Appendix A Watchdog Timer

    CAPA848 Capa Board Appendix A Watchdog Timer A.1 About Watchdog Timer After the system stops working for a while, it can be auto-reset by the watchdog timer. The integrated watchdog timer can be set up in the system reset mode by program.
  • Page 82 CAPA848 Capa Board This page is intentionally left blank. Watchdog Timer...

  • Page 83: Appendix B Digital I/O

    CAPA848 Capa Board Appendix B Digital I/O B.1 About Digital I/O The onboard digital I/O has 8 bits (DIO0~7). Each bit can be set to function as input or output by software programming. In default, all pins are pulled high with +5V level (according to main power).

  • Page 84: B.2 Digital I/O Programming

    CAPA848 Capa Board B.2 Digital I/O Programming The following example enables configuration using debug tool. Start digital I/O programming  Enable configuration: O 2E 87 ; Un-lock super I/O O 2E 87  Select logic device: O 2E 07 O 2F 07 ...
