9. IsoData data string
In IsoData mode, the ISOMETER® continuosly sends the whole data string with a cycle
time of approximately 1 second. Communication with the ISOMETER® within this mode
is not possible and no additional sender may be connected via the RS-485 bus cable.
IsoData is activated in the menu "out", menu item "Adr" when it has been set to Adr = 0.
In this event, the symbol "Adr" flashes on the measuring value display.
String
!; Start symbol
v; Insulation fault location ' ' / '+' / '-'
Insulation resistance R [kΩ]
1234, 5;
F
12345; System leakage capacitance
123456; reserved
Nominal system voltage
+1234;
Nominal system voltage type:
Residual voltage U
+1234;
L+e
Residual voltage U
+1234;
L-e
+123; Insulation fault location -100 ... +100 [%]
123456; reserved
Alarm message [hexadecimal] (without leading "0x")
The alarms are included in this value with the OR function.
Assignment of the alarms:
0x0002 Device fault
0x0004 Prewarning insulation resistance R
0x0008 Prewarning insulation resistance R
0x000C Prewarning insulation resistance R
1234;
0x0010 Alarm insulation resistance R
0x0020 Alarm insulation resistance R
0x0030 Alarm insulation resistance R
0x0040 Alarm undervoltage U
0x0080 Alarm overvoltage U
0x0100 Message system test
0x0200 Device start with alarm
Update counter, consecutively counts from 0 to 99.
12
It increases with the update of the insulation resistance value.
<CR><LF> String end
27
Description
C [nF] (only in „GEn" setting)
e
U [V ]
n trueRMS
DC: '+' / '-'
[V ]
DC
[V ]
DC
at L+
F
at L-
F
symmetrical
F
at L+
F
at L-
F
symmetrical
F
n
n
IsoData data string
