Function
Internal device errors E.xx can be caused by external disturbances or internal hardware
errors. If the error message occurs again after restarting the device or after a reset to
factory settings (menu item "FAC") , the device must be repaired. After eliminating the
fault, the alarm relays switch back automatically or by pressing the reset button. The self
test can take a few minutes.
It can be suppressed for the duration of the device start by setting the parameter in the
menu "SEt" to "S.Ct = off". This allows the ISOMETER® to enter measurement mode quickly
after connecting the supply voltage U
Automatic self test
The device runs a self test after connecting the supply voltage U
lectable at „t" menu on page 17 : off, 1h, 24 h).
Manual self test
By pressing the external test/reset button or the test button "T" on the device for > 1.5 s,
a self test is started. While holding down the test button "T", all device-relevant display
elements appear on the display.
3.2.7 Malfunction
In addition to the described self test, several functions in the insulation monitoring de-
vice are continuously checked during operation. If a fault is detected, the device error
("Err") will be signalled, the error code "E.xx" appears on the display as an identifier for the
error type xx and the LEDs "ON"/"AL1"/"AL2" will flash.
If the error occurs again after restarting the device or after restoring the factory settings,
please contact Bender Service.
3.2.8 Signalling assignment of the alarm relays K1/K2
The notifications for "device error," "insulation fault", "insulation impedance fault",
"undervoltage/overvoltage fault", "device test" and "device start with alarm" can be as-
signed to the alarm relays via the "out" menu. An insulation fault is indicated by the
messages "+R1", "-R1", "+R2" and "-R2". Messages "+R1" and "+R2" indicate an insulation
fault assigned to conductor L+, and the messages "-R1" and "-R2" indicate an insulation
fault assigned to conductor L-.
The message "test" indicates a self test.
The message "S.AL" indicates a so-called "device start with alarm". After connecting to the
supply voltage U and setting the parameter value to "S.AL = on", the ISOMETER® starts
s
with the insulation measured value R
be cleared only when the measured values are up-to-date and no thresholds are ex-
ceeded. In the factory setting "S.AL = off", the ISOMETER® starts without an alarm. It is
recommended that the value set for the "S.AL" parameter value is identical for both re-
lays.
10
.
s
and later every 24 h (se-
s
= 0 Ω and sets all activated alarms. The alarms will
F
Function
3.2.9 Measuring and response times
Operating time
ae
The operating time t is the time required by the ISOMETER® to determine the measured
ae
value. For the insulation measuring value R
voltages U und U and the fault location R%, it is dependent on the insulation re-
L+e L-e
sistance R and the system leakage capacitance C
F
longer operating times. The measuring time of the mains voltage U
this and significantly shorter.
Response delay
on
The response delay t can be set uniformly for all messages in the "t" menu using the
on
parameter "ton", whereby each alarm message specified in the alarm assignment hast its
own timer for t . This delay time can be used for interference suppression in the case of
on
short measuring times.
An alarm will only be signalled when a threshold value of the respective measuring value
is violated for the period of t without interruption. Every time the threshold value is vi-
on
olated within the time t , the response delay "ton" restarts once again.
on
Total response time
an
The total response time t is the sum of the operating time t
an
time t .
on
Delay on release
off
The delay on release t can be set uniformly for all messages in the "t" menu using the
off
parameter "toff", whereby each alarm message specified in the alarm assignment hast its
own timer for t . An alarm will continuously be signalled until the threshold value of the
off
respective measured value is not violated (including hysteresis) for the period of t
without interruption. Each time the threshold value is not violated for the period of t
the delay on release "toff" restarts once again.
Start-up delay
After connection to the supply voltage U
(0...10 s) in the parameter "t" is suppressed.
, the system leakage capacitance C
F
. System interferences can lead to
e
is independent of
n
and the response delay
ae
the alarm indication for the preset time
S
