Bender ISOMETER isoCHA425 Manual page 23

Modbus register assignment of the ISOMETER®
Register Property Description
3016 RW Baud rate "Adr 1"
3017 RW Parity "Adr 2"
Start-up delay "t" dur-
3018 RW
ing device start
Response delay "ton"
3019 RW
for relays K1 and K2
Delay on release "toff"
3020 RW
for relays K1 and K2
Repetition time "test"
3021 RW for automatic
device test
3022 RW Reserved
3023 RW Reserved
Test of the system con-
3024 RW nection during device
test "nEt"
Device test during
3025 RW
device start "S. Ct"
Request stop mode
3026 RW
(0 = deactivate device)
Alarm assignment of
3027 RW
relay 1 "r1"
Alarm assignment of
3028 RW
relay 2 "r2"
23
Format Unit Value range
0 = BMS
1 = 1.2 k
2 = 2.4 k
3 = 4.8 k
UINT 16 --- 4 = 9.6 k
5 = 19.2 k
6 = 38.4 k
7 = 57.6 k
8 = 115.2 k
0 = 8N1
UINT 16 --- 1 = 8O1
2 = 8E1
UINT 16 s 0 ...10
UINT 16 s 0 ... 99
UINT 16 s 0 ... 99
0 = OFF
UINT 16 --- 1 = 1 h
2 = 24 h
--- --- ---
--- --- ---
0 = off
UINT 16 ---
1 = on
0 = off
UINT 16 ---
1 = on
0 = Stop
UINT 16 ---
1 = ---
Bit 9 ... Bit 1
UINT 16 --- (see
chapter 8.1.3)
Bit 9 ... Bit 1
UINT 16 --- (see
chapter 8.1.3)
Modbus register assignment of the ISOMETER®
Register Property Description
Factory settings for all
8003 WO
parameters
Factory setting only
8004 WO for parameters resetta-
ble by FAC
8005 WO Start device test
8006 WO Clear fault memory
9800
RO Device name
bis 9809
Software
9820 RO
ID number
Software version
9821 RO
number
9822 RO Software version: Year
Software version:
9823 RO
Month
9824 RO Software version: Day
9825 RO Modbus driver version
RW = Read/Write; RO = Read only; WO = Write only
Format Unit Value range
UINT 16 --- 0x6661 „fa"
UINT 16 --- 0x4653 „FS"
UINT 16 --- 0x5445 „TE"
UINT 16 --- 0x434C „CL"
UNIT 16
(ASCII) -
--- ---
siehe
chapter 8.1.1
Software ID
UINT 16 ---
Number
Software
UINT 16 ---
version
UINT 16
UINT 16
UINT 16
UINT 16
isoCHA425_D00352_01_M_XXEN/10.2019
