ADTEK CS2-MC Manual page 19

【AO Group】
Name Address
004Eh
004Fh
0050h
0051h
【RS485 Group】
Name Address
0056h
0057h
0058h
Range
0~5 Analog Output Type
0: 0~10V
3: 0~20mA
0~2 Analog Output Selection
0: Batch
0~3 The clear of AO_ZERO and AO_SPAN
0: None 1: AO_ZERO 2: AO_SPAN 3:
Both
00.00%~110.00% Analogue Output High Limit
Range
1~255 RS485 address
0~5 RS485 baud rate
0:1200
4:19200
0~3 RS485 parity
0: n-8-1 1: n-8-2 2: odd 3: even
Explain
1: 0~5V 2:1~5V
4: 4~20mA 5: 0~10mA
1: Batch Counter
Explain
1:2400 2:4800 3:9600
19 / 19
Initial Write/Read Note
4
2
2: Totalizer
0
11000
Initial Write/Read Note
1
3
1
CS2-MC Manual 2014/9/9
R/W
R/W
R/W
R/W
R/W
R/W
R/W
