EXTERNAL CONTROL INPUT(E.C.I.) GRUOP
Default
rY2.ot:Relay 2 energized time
(N mode is no such function)
rY3.Md:Relay 3 energized mode ....as Relay 1 Energized
rY3.ot:Relay 3 energized time)
(N mode is no such function)
rY4.Md:Relay 4 energized mode ....as Relay 1 Energized
rY3.ot:Relay 3 energized time):
(N mode is no such function)
DESCRIPTION
EXTERNAL CONTROL INPUT
GROUP INDEX
ECi.1: External Control Input 1
ECi.2:External Control Input 2
Setting Range:
0:00.0~9m:59.9s
Shift
Mode
oFF / btcH.n / btCH.r /
btCH.C / btCH.E / totL.n /
totL.r / totL.C / totL.E / do
Setting Range:
0:00.0~9m:59.9s
Shift
Mode
oFF / btcH.n / btCH.r /
btCH.C / btCH.E / totL.n /
totL.r / totL.C / totL.E / do
Setting Range:
0:00.0~9m:59.9s
Shift
In following page, press
for 1 second to back
EXTERNAL CONTROL
INPUT GROUP INDEX.
Setting Range:nonE GAtE
nonE(None): No function
GAtE(Gate): This feature is
batch & total suspended
rESEt:Reset for Totalizer &
Batch
tL.GtE(Gate for Totalizer):
This feature is total
suspended
tL.rSt:Reset for Totalizer
bt.GtE(Gate for Batch): This
feature is batch
suspended
bt.rSt:Reset for Batch
&
same as ECI1
...other as same as ECI1...
nonE / GAtE / rESEt / tL.GtE
/ tL.rSt / bt.GtE / bt.rSt
&
12 / 19
Up Down
Up Down
Up Down
PARAMETERS
rESEt tL.GtE
tL.rSt bt.GtE
bt.rSt
Up&Down Enter
Up&Down Enter
