Jumper/Switch Functions
S6 Serial Interface format
S7 Channel 2 input source selector
S8 Channel 1 input source selector
(2)
Refer to Section 5.5.1
5.2 Power-Down, MODE, and FORMAT Control
The ADS1278-SP has several pins to control the power-down of individual channels and select the mode
and format for the digital interface.
For users of the ADS1278EVM-CVAL as a stand-alone module, these pins may be pulled high or low
through DIP switches S1 and S2 (see
details on these pins and which state sets which options.
For use with the MMB0 motherboard, the state of these pins is controlled by software, using the I
expanders (U7 and U8) on the EVM. With this configuration, the DIP switches S1 and S2 must all be
switched up (away from the center of the board). The ADS1278EVM-CVAL software checks at startup to
verify that these switches are set correctly, and generates an error message for incorrect settings. The
software cannot detect if the switches are changed after startup.
When using the ADS1278EVM-CVAL with the MMB0 motherboard, the DIP
switches S1 and S2 must all be switched up (away from the center of the
board). Failure to do so may damage the EVM.
5.3

Clock Source

The ADS1278-SP clock can come from one of several sources: the onboard 27-MHz crystal oscillator, a
clock supplied by a processor on the TOUT pin (J4.17), or an external clock source connected between
J4.17 (TOUT) and J4.18 (DGND).
If the onboard 27-MHz oscillator is selected, the device can be run in high-speed mode, high-resolution
mode, low-power mode, or low-speed modes with CLKDIV set to 1.
If the performance of the device must be explored with CLKDIV set to 0 in the low-power and low-speed
modes, an external clock must be provided to the board, either using the TOUT connection or having an
external clock source connected to J4.17. The same condition is true if frequencies other than the 27 MHz
provided by the onboard oscillator must be investigated.
5.4 Analog Headers, J1 and J3
For maximum flexibility, the ADS1278EVM-CVAL is designed for easy interfacing to multiple analog
sources. These headers/socket provide access to the analog input pins of the ADS1278-SP.
Four of the analog input sources (Channels 1–4) connect directly to J3 (top or bottom side) or through
signal-conditioning modules available for the modular EVM system. These inputs have provisions to buffer
the inputs using THS4521 before connecting to the converter. Switches S4, S5, S7, and S8 provide the
capability to connect either the header directly or through a buffer. When the buffers are not selected, the
op-amps used for buffering can be powered down by shorting JP3.
