Summary of Contents for Texas Instruments ADS1202EVM
- Page 1 All manuals and user guides at all-guidesbox.com ADS1202 Modular EVM User’s Guide August 2003 Data Acquisition - Digital/Analog Converters) SLAU111...
- Page 2 TI product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such statements. Following are URLs where you can obtain information on other Texas Instruments products & application solutions:...
- Page 3 All manuals and user guides at all-guidesbox.com EVM IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including product safety measures typically found in the end product incorporating the goods.
- Page 4 EVM schematic located in the EVM User’s Guide. When placing measurement probes near these devices during operation, please be aware that these devices may be very warm to the touch. Mailing Address: Texas Instruments Post Office Box 655303 Dallas, Texas 75265 Copyright 2003, Texas Instruments Incorporated...
- Page 5 All manuals and user guides at all-guidesbox.com Information About Cautions and Warnings Preface Read This First About This Manual This users guide describes the characteristics, operation, and use of the ADS1202 Modular EVM. A complete circuit description as well as schematic diagram is included.
- Page 6 Operation of this equipment in other en- vironments may cause interference with radio communications, in which case the user at his own expense will be required to take whatever measures may be required to correct this interference. Trademarks TI logo is a trademark of Texas Instruments.
-
Page 7: Table Of Contents
All manuals and user guides at all-guidesbox.com Contents Contents EVM Overview ..............Analog Interface . - Page 8 All manuals and user guides at all-guidesbox.com...
-
Page 9: Evm Overview
The new modular EVM form factor allows for direct evaluation of the ADC’s performance and operating characteristics. This EVM is compatible with the 5 - 6K Interface Board (SLAU104) from Texas Instruments. Direct modulator output Various isolation options... -
Page 10: Analog Interface
All manuals and user guides at all-guidesbox.com Analog Interface 1.1 Analog Interface The ADS1202 modular EVM is designed for easy interfacing to multiple analog sources. Samtec part numbers SSW-110-22-F-D-VS-K TSM-110-01-T-DV-P provide a convenient 10-pin dual row header/socket combination at J1. Connector J1 provides access to the ADS1202 input pins. The modulator + input terminal is connected to pin 2, the - input terminal is connected to pin 4. -
Page 11: Power Supply Options
All manuals and user guides at all-guidesbox.com Chapter 2 Power Supply Options The ADS1202 modular EVM board requires 5-V dc for the ADS1202 circuit. When used in combination with the 5- 6K interface boards, J5 (located on the bottom side of the PWB) provides connection to the common power bus described in document SLAU104. - Page 12 All manuals and user guides at all-guidesbox.com...
-
Page 13: Evm Operation
TP1 to TP7) To verify the ADS1202EVM is functional, arrange W1 and W2 for Mode 0 operation by ensuring the shunt jumpers are installed (factory default conditions). Apply 5-V power to the EVM through J3. Apply a 200-kHz sinusoidal wave (250 mV ) to J1.2 referenced to J1.4. - Page 14 All manuals and user guides at all-guidesbox.com Using an oscilloscope view the MCLK and MDAT output signals on J2.5 and J2.13 respectively. The outputs should look similar to those in the following figure: Slowly increase the time base of the oscilloscope. As the time base increases, the sine wave applied to the input terminals should begin to appear on the oscilloscope screen as shown below.
-
Page 15: Ads1202 Modular Evm Bom And Schematic
All manuals and user guides at all-guidesbox.com Chapter 4 ADS1202 Modular EVM BOM and Schematic This chapter contains the bill of materials and the schematic Topic Page Bill of Materials ..........Schematic . -
Page 16: Ads1202 Modular Evm Bom
All manuals and user guides at all-guidesbox.com ADS1202 Modular EVM BOM 4.1 ADS1202 Modular EVM BOM The following table contains a complete bill of materials for the ADS1202 EVM. Table 4 - 1. Bill of Materials Designators Description Manufacturer Mfg. Part Number C1, C8 1 nF, 0805, ceramic, NPO, 50 V, 5% PhyComp... -
Page 17: Schematic
All manuals and user guides at all-guidesbox.com Schematic 4.2 Schematic The schematic diagrams are shown on the following pages. ADS1202 Modular EVM BOM and Schematic... - Page 18 All manuals and user guides at all-guidesbox.com Revision History ECN Number Approved AVdd ISO_Vd +5Va 0.01uF 0.1uF ISO_GND VIN+ ISO_MCLK MCLK 11 12 11 12 ISO_MDAT 13 14 VIN- MDAT MCLK 13 14 15 16 15 16 17 18 17 18 19 20 19 20 ADS1202...
- Page 19 All manuals and user guides at all-guidesbox.com Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments ADS1202EVM...
