Quick Start
This section provides a QuickStart guide to quickly begin evaluating the ADS1278EVM-CVAL with
ADCPro.
2.1
Default Jumper/Switch Configuration
Figure 1
and
Table 2
SBAU324 – September 2018
Submit Documentation Feedback
show the factory default jumper positions for the MMB0 motherboard EVM.
Figure 1. MMB0 Default Jumper Positions
Table 2. MMB0 Default Jumper Positions
Jumper
J12
J13A
J13B
Copyright © 2018, Texas Instruments Incorporated
Position
CLOSED
OPEN
CLOSED
ADS1278EVM-CVAL Evaluation Module User's Guide
Quick Start
