Contents and general instructions

Notes on the use of this manual

Documentation on the Checkbox

Manual
Documentation on the Checkbox:
– Identbox, Countbox, Sortbox:
type P.BE-Checkbox-..
– Checkbox Compact Classic, PLC
type P.BE-CB-COMP-..
Manuals on software packages
– Checkbox Configurator:
type P.SW-CB-KON-..
– Checkbox Optimizer:
type P.SW-CB-OPTI-..
XII
This manual refers to the standard designs of the Checkbox
Compact Classic (type CHB-C-C) and Compact PLC (type
CHB-C-P) with operating system version 3.x.
When the Checkbox is switched on, the version number of the
operating system will be displayed briefly (see chapter 2.4).
The options and parameters available depend on the operat-
ing system, the type of Checkbox connected and the pre-set-
tings made at the factory. Special customer-specific designs
may differ in technical data, parameter settings and function-
ality.
The pre-setting of the Checkbox can be modified if required
with the software packages CheckKon (function "Modify sys-
tem") or CheckOpti (see chapter 1.2).
Information on using the Checkbox can be found in the fol-
lowing manuals:
Contents
Description of the function, commissioning,
operation and maintenance of the relevant
Checkbox type.
Operating the Checkbox Configurator
Operating the Checkbox Configurator
Festo P.BE-CB-COMP-EN en 0211a
