Festo Checkbox Compact CHB-C-C Manual page 128

A. Technical appendix
A-26
Accessories
Opto-electronic sensors, cylindrical construction form
Reflex light push button
Cable connection, separate
clamping space required
– M12
– M18
Inductive sensors, cylindrical construction form
with standard switching distance, can be connected directly to
Duo cable
Fitting diameter
– 4 mm
– 6.5 mm
Connections BUFFER/FEEDER and ACTUATORS
Adapter cable (Duo cable)
Extension cable 2.5 m
Extension cable 5 m
Sensor plug M12
– 4-pin
– 4-pin
Duo plug M12, 2 cables
– 4-pin
Connection PLC
Binder plug
– 24-pin with 5 m cable
length
Type Order
no.
SOEG-RT-M12-PS-K-L 165338
SOEG-RT-M18-PS-K-L 165342
SIEN-4B-PO-S-L 150367
SIEN-4B-PO-S-L 150383
18685
18684
18686
SAE-4GS-7-2,5 18666
SEA-GS7 192008
SEA-GS-11-DUO 18779
CHB-C-P 665967
