Operating displays
Display during the teach procedure
1 o...
Memory group of the parts type and
number of the sample part orientation
during the teach procedure
? ... Selection of the memory group of the
parts type
C... Scatter of characteristics (C-value)
<10: Sample parts are very similar in
all features.
>30: Large scatter of at least one
feature
tool
Memory address assigned with measuring tool or
optimized teach data (CheckOpti)
Display during test procedure
1 5 Tolerance value for the current parts type
1. Number: Number of the parts type
2. Number: Tolerance in %
A... Test part deviation: The smaller
the value, the more exact the test part
corresponds to saved sample parts.
≤100: Good part
>100: Bad part
The smaller the value, the more reliably
#...
the test part orientation can be recog-
nized.
<100: Test part orientation can be
assigned
>100: Test part orientation cannot be
assigned clearly
Full Status of buffer zone (signal from buffer zone sensor)
cFul Preselected counter reading reached
Value
1...8
Checkbox PLC:
1...4
0...999
Value
1. Number:
Checkbox
Classic: 1
Checkbox PLC:
1...4
2. Number:
0...20
0...999
0...999
