A. Technical appendix
A-10
Operating displays
Table fields with a grey background indicate continuous displays;
the remaining displays are shown only for a brief period due to an
event or operating status.
Display when the Checkbox is switched on
IC30 Identification code and version status of the operating
system
4..E
Number of memory groups or parts types and also the
letter E with system setting "with encoder."
Example: 4 memory locations, encoder
2048
System setting of the camera resolution.
Example: 2048 pixels
Stop The Checkbox is in the stop status.
Display with control panel lock
Lock Display in the stop status or for 1.5 s when the START/
STOP button is pressed.
Blocking the keys START/STOP and STATUS/TEACH via
PLC programming A change of operating mode is con-
trolled exclusively by the PLC (see chapter 4.3.1).
Fix Display for 1.5 s when the STATUS/TEACH button lock of
the STATUS/TEACH key is pressed via the CheckKon con-
figuration software (parameter "System/operating mode
locking of the Teach button = ..."). The Checkbox can be
started or stopped manually. A change to the teach mode
is not possible. The Checkbox remains in auto mode.
Fault message
Details in chapter A.1.2.
E... Fault code for system fault
F... Warning
01...99
05
