Note. The exception
to all this is the
Direction Protection
option, which has
only a Default button
and a checkbox
to turn direction
protection on and off.
Note. Each of these
settings affects
only the lane you
clicked on.
 SmartSensor HD User Guide
80
Adjusting lane properties and thresholds
Click on the lane you wish to adjust. The Lane Adjustment
1
window will appear.
Choose the desired property from the drop-down menu (see
2
the table that follows for more info).
To make adjustments to one lane, use the slider, number field,
3
and/or Default button next to the lane name. Additionally, if the
checkbox next to the lane name is checked, you can adjust that
lane using the tools next to the the Selected row at the top of
the screen.
To make adjustments to all lanes, click the checkbox next to the
4
Selected row at the top of the screen; all lanes will be automat-
ically selected. Now use the slider, number field, and/or Default
button to make desired changes.
Click OK.
5
Setting
Volume
Description
Adjusts the
aggressiveness of
traffic radar–specific
algorithms.
Details
Adjust this setting if
you observe a count
accuracy problem.
Adjust the percentage
up to increase the
number of detections
and down to
decrease.
You'll likely need to
adjust at least 10–15%
in either direction
(possibly much more);
adjusting less may not
impact detections. We
recommend you keep
the slider between 20
and 190%.
