SmartSensor HD User Guide
22
•
L L N G G
Figure 16. Connecting sensor cable to terminal blocks
Insert the sensor cable (the pigtail cable coming from the
6
sensor) into the middle grip on the bottom of the box. Twist the
cable grip to tighten.
Follow the instructions in step 4 to land each conductor into
7
the correct terminal block. The blocks are color-coded for your
convenience: land the red conductor into the block with the red
label, and so on.
+DC +DC -DC -DC GND GND 485- 485- 485+ 485+ GND GND RTS RTS CTS CTS TD TD RD RD GND GND GND GND
