Using the Lane window

Click a saved (black) lane in the edit area to open this window.
Setting
Name
Figure 67. Lane window
Description
Lets you type in a
new lane name.
Details
SSMHD uses "LANE_
xx" as the default ("xx"
is the number of the
name, with LANE_01
nearest the sensor).
When you add a new
lane, all lanes with this
name format will be
updated.
For RTMS and Z4
data push, lane
mapping may be
changed using the
notation #xx ("xx"
being a lane number).
All lanes must use this
format for the new
lane mapping to take
effect.
Chapter 6: Configuring Lanes
Note. If you decide
to renumber the
lanes manually, the
software won't let
you use "LANE_xx"
as the format,
but you can use
the lowercase
version, "Lane_xx",
if you'd like.
