Definition. Z4 is a
Wavetronix-specific
protocol that lets
sensors talk to other
Wavetronix devices,
mostly contact
closure devices.
Note. The Loop
Emulation settings
are found on the
Settings screen and
covered in chapter 5.
SmartSensor HD User Guide
96
•
Setting
All three pushed data types
HD
SS105 Simple
SS105 Multidrop
Event data only
Z4 2-Loop
Z4 1-Loop
Z4 2-Loop Pulsed
Description
Native SmartSensor
HD (SS125) format.
Emulates the original
SmartSensor (SS105)
format, without a
multi-drop header.
Emulates the original
SmartSensor (SS105)
format, with a multi-
drop header.
Emulates a dual-
loop system. Speed
and duration are
measured using the
loop size and spacing
set in the Loop
Emulation settings.
Emulates a single-
loop system. Duration
is measured using
the loop size set in
the Loop Emulation
settings.
Emulates a dual
loop system; outputs
will be held active
for 125 ms for each
vehicle detected, so
only speed will be
measured.
Details
Use this for a
standard SmartSensor
HD system.
Use this when
you're using the
SmartSensor HD
in a system that
was designed for a
SmartSensor 105.
Use this when
you're using the
SmartSensor HD
in a system that
was designed for a
SmartSensor 105.
Use this when
you're using the
SmartSensor HD in
a system that was
designed for dual
inductive loops.
Use this when
you're using the
SmartSensor HD in
a system that was
designed for single
inductive loops.
Use this when
you're using the
SmartSensor HD in
a system that was
designed for dual
inductive loops and
all you need is vehicle
presence and speed.
