Step 7
Run a wash program to verify that particles are removed.
Step 8
If particles not removed, consult Technical Support.
Removal of wash head
Step 1 Perform Empty Wash Head Procedure to drain wash head.
Step 2
Turn instrument off.
Step 3
Unscrew the wash head locking screws (2).
Step 4
Lift the wash head up slowly. Disconnect the air pressure supply
tube and the ribbon cable from the wash head.
Solenoid valves
Sensor block
Ribbon cable
Air pressure supply
Figure 9: Wash head connections
SkanStacker 300 User Guide
Maintenance
32
