Chapter 10
Column
Leaking Water Valve
Waiting For Water
Tank Fill
No Water Required
Too Much Water
Calculated
Prewet Target Not
Reached
Mix Too Wet
Rejected
Mix Too Dry
Rejected
Mix Too Wet
Accepted
Mix Too Dry
Accepted
Water Limit
Exceeded
Max Dry Mix Time
Exceeded
Max Wet Mix Time
Exceeded
Mix Aborted
Sensor Fault
Mixer Blades worn
Calibration Mix
*
The Unscaled Value for the selected Measurement Mode is added to this column.
Additional Columns for each available Measurement Mode are also saved to the Mix
Log (Only available for selected sensors)
3 Viewing the Mix Trace
To access details for a particular batch, select one of the batches from the list and then click the
View Mix Trace button. This will then display the mix trace page, which provides a graphical
Units
Description
A Leaking Water Valve alarm was triggered during the
batch.
A Waiting For Water Tank Fill alarm was triggered during
the batch.
A No Water Required alarm was triggered during the
batch.
A Too Much Water Calculated alarm was triggered
during the batch.
A Prewet Target Not Reached alarm was triggered
during the batch.
A Mix Too Wet alarm was triggered during the batch and
the mix was rejected by the operator.
A Mix Too Dry alarm was triggered during the batch and
the mix was rejected by the operator.
A Mix Too Wet alarm was triggered during the batch and
the mix was accepted by the operator.
A Mix Too Dry alarm was triggered during the batch and
the mix was accepted by the operator.
A Water Limit Exceeded alarm was triggered during the
batch.
A Max Dry Mix Time Reached alarm was triggered during
the batch.
A Max Wet Mix Time Reached alarm was triggered
during the batch.
The Mix was aborted during the batch.
The Sensor communication was lost during the batch.
Mixer Blades worn alarm Activated
Indicates if the Mix Log was used to calibrated the recipe
Hydro-Control VI Operators Guide HD0456 Rev 1.7.1
Using the Mix Log
65
