Using the Mix Log
Column
Cement Weight
Mix Temperature
Pre-wet
Moisture
Gain
Pre-wet
Moisture
Offset 1
Moisture Gain 1
Moisture Offset 1
Moisture Gain 2
Moisture Offset 2
Calc Gain
Calc Offset
Admix Enable %
2 step addition
Proportional Gain
Derivative Gain
Cement In Error
Water Meter Fault
64
Hydro-Control VI Operators Guide HD0456 Rev 1.7.1
Units
Description
This is the weight of the cement that was added to the
Kg/lbs
batch if it has been entered into the recipe or sent from
the batch control system.
°C/°F
Recorded temperature of the finished mix
This is the moisture gain used during the pre-wet mix
This is the moisture offset used in the pre-wet mix
This is the first Moisture Gain value used to calculate the
moisture for display.
This is the first Moisture Offset value used to calculate
the moisture for display.
This is the second Moisture Gain value used to calculate
the moisture for display. This is used to rescale the
graph after admixtures have been added to the mixer.
This is the second Moisture Offset value used to
calculate the moisture for display. This is used to rescale
the graph after admixtures have been added to the
mixer.
This is the Gain value used to calculate the quantity of
water to add to the mixer when running calculation mode.
This is the Offset value used to calculate the quantity of
water to add to the mixer when running calculation mode.
This is the point during the water addition phase at which
the Hydro-Control activates the Admix signal so that the
batch control system can begin dosing the admixtures.
It is based on the percentage of the total water that has
been added.
Indicates whether 2 step water addition was used
This is the Proportional Gain value used during the batch
if the system is running in Auto mode.
This is the Derivative Gain value used during the batch if
the system is running in Auto mode.
A Cement In alarm was triggered during the batch.
A Water Meter Fault alarm was triggered during the
batch.
Chapter 10
