Chapter 6
Recipe parameter
Wet Mix Time
Wet Mix Deviation
Using the Next button gives Page 3 of the recipe editor screen.
Calculation Mode Settings
1.6
Recipe parameter
Pre-wet Moisture Offset 1
Pre-wet Moisture Gain 1
Moisture Offset 1
Moisture Gain 1
Moisture Offset 2
Moisture Gain 2
Use Pre-wet value for main
water
Description
When using Auto-track control, this is the amount of time that the
Wet Mix must be within the Wet Mix Deviation below to continue.
If the sensor signal has not stabilised within this window by the end
of the Wet Mix Time, the system will prompt the operator to
continue regardless of whether it has stabilised or not.
This is the maximum deviation that the sensor signal must be within
in order for the system to continue.
Figure 13: The recipe editor screen (page 3)
Description
These are the calibration coefficients for the pre-wet phase of the
recipe. These define the relationship between the amount of
moisture in the batch and the unscaled sensor value. These are
automatically calculated when you calibrate a recipe.
These are the calibration coefficients for the recipe. These define
the relationship between the amount of moisture in the batch and
the unscaled sensor value. These are automatically calculated
when you calibrate a recipe.
These are the calibration coefficients for the recipe with the
admixture in. These are automatically calculated when you
calibrate a recipe using the two step preset method.
If enabled the Hydro-Control VI will use the reading measured at
the end of the pre-wet mix rather than the dry mix to calculate how
much water to add in the main water addition
Hydro-Control VI Operators Guide HD0456 Rev 1.7.1
Editing Recipes
31
