SPI Registers
8.6.11 SPI_XFERLEVEL Register (offset = 17Ch) [reset = 0h]
SPI_XFERLEVEL is shown in
This register provides the transfer levels required to use the FIFO buffer during transfer.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Bit Field
31-16 WCNT
15-8 AFL
7-0 AEL
304
SPI (Serial Peripheral Interface)
Figure 8-30 and described in
Figure 8-30. SPI_XFERLEVEL Register
WCNT
R/W-0h
Table 8-17. SPI_XFERLEVEL Register Field Descriptions
Type Reset
R/W 0h
R/W 0h
R/W 0h
Copyright © 2019, Texas Instruments Incorporated
Table 8-17.
9
AFL
R/W-0h
Description
SPI word counter.
This register holds the programmable value of the number of SPI
words to be transferred on the channel using the FIFO buffer.
When the transfer starts, a read back in this register returns the
current SPI word transfer index.
0h = Counter not used
1h = One SPI word
FFFEh = 65534 SPI word
FFFFh = 65535 SPI word
Buffer almost full.
This register holds the programmable almost-full level value used to
determine almost-full buffer condition.
If the user wants an interrupt or a DMA read request to be issued
during a receive operation when the data buffer holds at least n
bytes, then the buffer SPI_XFERLEVEL[AFL] must be set with n-1.
0h = 1 byte
1h = 2 bytes
Fh = 16 bytes
Buffer almost empty.
This register holds the programmable almost-empty level value used
to determine almost-empty buffer condition.
If the user wants an interrupt or a DMA write request to be issued
during a transmit operation when the data buffer is able to receive n
bytes, then the buffer SPI_XFERLEVEL[AEL] must be set with n-1.
0h = 1 byte
1h = 2 bytes
Fh = 16 bytes
www.ti.com
8 7 6 5 4 3 2 1
AEL
R/W-0h
