Teldat S.A.
Underside panel
Fig. 5:
The following table contains details on the significant elements on the underside panel.
Underside panel elements table
Item
A
B
C
3.1.5 Top Panel (LEDs)
The LEDs panel provides information on the state of the components (whether they are active or not) or on the net-
work activity.
Teldat K/KF router
Description
SIM tray for the internal module. This is only found on the Teldat K. It's accessed
from the underside of the router.
Platform where the label containing the information on the product is placed. This
label contains information on the device model, mac, serial number, etc.
Slots for wall mount.
3 Components and Power Supply
7
