3 Components and Power Supply
The other SIM tray belongs to the internal 3G module, only available in the Teldat K. To access it, you need to go to
the underside of the router and open the flap that is shown in the following figure to insert the SIM card.
Internal module SIM tray
Fig. 19:
Follow these instructions to insert the SIM: first locate the slot and remove the flap (at this stage, the SIM tray is vis-
ible). Then:
(1) Push the fastening in the direction indicated in the OPEN label until the SIM card tray is released.
(2) Lift the upper part of the tray.
(3) Fully insert the SIM card between the guides.
(4) Return the insertion tray to its original position.
(5) Gently press on the insertion tray and push the fastening towards the inside. The card should be fully inserted.
Instructions to insert the SIM in the internal module
Fig. 20:
18
Teldat S.A.
Teldat K/KF router
