DB-87040 / DB-87060 User's Manual
4-axes or 6-axes motion control wiring signals
Connector: SCSI-II 100-pin pin type
Signal: 4-axes or 6-axes motion control board signals
Dedicated Digital Input and Output
D/I Signal: HOME, OT+, OT-, STOP (Emergency Stop)
D/O Signal: INH (Output Inhibits) and RDY (Servo Ready)
Operation: DIP switch forced setting or normal
Input Signal: Opto-isolation low active
Output Signal: OPEN COLLECTOR
General Environment
Power: external +24V
Operating Temperature: 0-60°C
Storage temp: -20 to 70°C
Humility: 0 to 90 non-condensing
Humility: 0 to 90%
Dimensions: 245 mm x 108 mm
Mechanism: DIN-Rail terminal block
2
Introduction
