DB-87040 / DB-87060 User's Manual
the simulated OT+ Sensor is enabled and OFF indicates disable.
OT- : Parallel connection with TB1. OT- should be set OFF when
it connected with the external OT- Sensor. The Dip Switch is
simulated as the external OT+ Sensor when the actual external
OT- Sensor is not connected. Set the Dip Switch ON indicates the
simulated OT- Sensor is enabled and OFF indicates disable.
MODE : Reserved (Not Available)
INH : Parallel connection with Connector J1, J2, J3, J4, J5 and J6
of each driver. INH should be set OFF if the Servo On signal is
provided by software. It should be set ON if the Servo On signal
is provided by hardware device. The Dip Switch is simulated as
the function of Servo On. Set the Dip Switch ON indicates the
simulated Servo On signal is enabled and OFF indicates disable.
Hardware Setting 7
