AXIOMTEK DB-87040 User Manual page 17

Definition
~XENC_INB3
XENC_INC3
~XENC_INC3
XENC_INA5
~XENC_INA5
XENC_INB5
~XENC_INB5
XENC_INC5
~XENC_INC5
XDDA_OUTA1
~XDDA_OUTA1
XDDA_OUTB1
~XDDA_OUTB1
XDDA_OUTA3
~XDDA_OUTA3
XDDA_OUTB3
~XDDA_OUTB3
XDDA_OUTA5
~XDDA_OUTA5
XDDA_OUTB5
~XDDA_OUTB5
*J7 connect to DASP-52504 or DASP-52506 axes control card
Hardware Setting
DB-87040 / DB-87060 User's Manual
SCSI II-100PIN CONNECTOR
pin pin
30 80
31 81
32 82
33 83
34 84
35 85
36 86
37 87
38 88
39 89
40 90
41 91
42 92
43 93
44 94
45 95
46 96
47 97
48 98
49 99
50 100
Definition
~XENC_INB4
XENC_INC4
~XENC_INC4
XENC_INA6
~XENC_INA6
XENC_INB6
~XENC_INB6
XENC_INC6
~XENC_INC6
XDDA_OUTA2
~XDDA_OUTA2
XDDA_OUTB2
~XDDA_OUTB2
XDDA_OUTA4
~XDDA_OUTA4
XDDA_OUTB4
~XDDA_OUTB4
XDDA_OUTA6
~XDDA_OUTA6
XDDA_OUTB6
~XDDA_OUTB6
13
