13 Overview of the onsite display operating menu
Depending on the parameter configuration, not all submenus and parameters are
available. Information on this can be found in the parameter description under
"Prerequisite".
Level Level Level Level
0 1 2 3
KYL If "KYL" is shown on the display, this means that the keys of the device are locked.
To unlock the keys, see →  28
SP1
RP1
FH1
FL1
SP2
RP2
FH2
FL2
STL
STU
EF FUNC
OFF
4)
I
PNP
UNI
BAR
KPA
MPA
PSI
ZRO
GTZ
TAU
I
GTL
GTU
FCU
MIN
MAX
HLD
dS1
dR1
Ou1
HNO
HNC
Overview of the onsite display operating menu
Description
Switch point value, output 1
Switchback point value, output 1
Upper value for pressure window, output 1
Lower value for pressure window, output 1
Switch point, output 2
Switchback point, output 2
Upper value for pressure window, output 2
Lower value for pressure window, output 2
Value for 4 mA (LRV)
Value for 20 mA (URV)
Extended functions
Unit bar
Unit kPa (depends on the sensor measuring range)
Unit MPa (depends on the sensor measuring range)
Unit psi
Zero point configuration
Zero point adoption
Damping
Current output
Pressure applied for 4mA (LRV)
Pressure applied for 20mA (URV)
Alarm current
In the event of an error: MIN (≤3.6 mA)
In the event of an error: MAX (≥21 mA)
Last current value (HOLD)
Switching delay time, output 1
Switchback delay time, output 1
Output 1
NO contact for hysteresis function
NC contact for hysteresis function
Details
→  63
→  63
→  63
→  63
→  65
→  65
→  65
→  65
→  40
→  41
→  40
-
-
-
→  58
-
-
-
-
→  38
→  38
→  60
-
→  41
→  42
→  62
-
-
-
→  67
→  67
-
→  70
→  70
