Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Overview
A
A0022015
Endress+Hauser
3

Product description

3.1

Product design

B
A0037236
D
E
D
E
D
E
3.2

Function

3.2.1 Calculating the pressure
Devices with ceramic process isolating diaphragm (Ceraphire
The ceramic sensor is an oil-free sensor, i.e. the process pressure acts directly on the
robust ceramic process isolating diaphragm and causes it to deflect. A pressure-dependent
Item
A
C
B
C
A0037238
D
E
A0027226
A0027215
A0027227
Product description
Description
Valve plug
Cable
M12 plug
Housing cap made of plastic
Housing
Process connection (sample illustration)
® )
11
