Technical data
Sensor Device
Devices for gauge pressure measurement
4)
400 mbar (6 psi) PTP31B
PTP33B
4)
1 bar (15 psi) PTP31B
PTP33B
4)
2 bar (30 psi) PTP31B
PTP33B
4)
4 bar (60 psi) PTP31B
PTP33B
4)
10 bar (150 psi) PTP31B
PTP33B
4)
40 bar (600 psi) PTP31B
PTP33B
4)
100 bar (1 500 psi) PTP31B –1 (–15)
4)
400 bar (6 000 psi) PTP31B –1 (–15)
Devices for absolute pressure measurement
4)
400 mbar (6 psi) PTP31B
PTP33B
4)
1 bar (15 psi) PTP31B
PTP33B
4)
2 bar (30 psi) PTP31B
PTP33B
4)
4 bar (60 psi) PTP31B
PTP33B
4)
10 bar (150 psi) PTP31B
PTP33B
4)
40 bar (600 psi) PTP31B
PTP33B
4)
100 bar (1 500 psi) PTP31B 0 (0)
4)
400 bar (6 000 psi) PTP31B 0 (0)
1) Highest turn down that can be set at the factory: 5:1. The turn down is preset and cannot be changed.
2) Other measuring ranges (e.g. –1 to +5 bar (–15 to 75 psi)) can be ordered with customer-specific settings (see the Product Configurator, order
code for "Calibration; Unit" option "U"). It is possible to invert the output signal (LRV = 20 mA; URV = 4 mA). Prerequisite: URV < LRV
3) Product Configurator, order code for "Sensor range"
4) Vacuum resistance: 0.01 bar (0.145 psi) abs
78
Maximum turn down which can be ordered for absolute pressure and gauge pressure
sensors
Devices for gauge pressure measurement
• 6 bar (90 psi), 16 bar (240 psi), 25 bar (375 psi): TD 1:1 to TD 2.5:1
• All other measuring ranges: TD 1:1 to TD 5:1
Devices for absolute pressure measurement
• 100 mbar (1.5 psi), 250 mbar (4 psi), 400 mbar (6 psi): TD 1:1
• 1 bar (15 psi): TD 1:1 to TD 2.5:1
• All other measuring ranges: TD 1:1 to TD 5:1
Metal process isolating diaphragm
Maximum
Sensor measuring range
lower (LRL) upper (URL)
[bar (psi)] [bar (psi)]
–0.4 (–6) +0.4 (+6)
–1 (–15) +1 (+15)
–1 (–15) +2 (+30)
–1 (–15) +4 (+60)
–1 (–15) +10 (+150)
–1 (–15) +40 (+600)
+100 (+1500) 20 (300)
+400 (+6000) 80 (1200)
0 (0) 0.4 (+6)
0 (0) 1 (+15)
0 (0) 2 (+30)
0 (0) 4 (+60)
0 (0) 10 (+150)
0 (0) +40 (+600)
+100 (+1500) 20 (300)
+400 (+6000) 80 (1200)
Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Lowest MWP OPL
calibratable
1)
span
[bar (psi)] [bar (psi)] [bar (psi)]
0.4 (6) 1 (15) 1.6 (24)
0.4 (6) 2.7 (40.5) 4 (60)
0.4 (6) 6.7 (100.5) 10 (150)
0.8 (12) 10.7 (160.5) 16 (240)
2 (30) 25 (375) 40 (600)
8 (120) 100 (1500) 160 (2400) 0 to 40 bar (0 to 600 psi)
100 (1500) 160 (2400) 0 to 100 bar (0 to 1 500 psi)
400 (6000) 600 (9000) 0 to 400 bar (0 to 6 000 psi)
0.4 (6) 1 (15) 1.6 (24)
0.4 (6) 2.7 (40.5) 4 (60)
0.4 (6) 6.7 (100.5) 10 (150)
0.8 (12) 10.7 (160.5) 16 (240)
2 (30) 25 (375) 40 (600)
8 (120) 100 (1500) 160 (2400) 0 to 40 bar (0 to 600 psi)
100 (1500) 160 (2400) 0 to 100 bar (0 to 1 500 psi)
400 (6000) 600 (9000) 0 to 400 bar (0 to 6 000 psi)
2)
Factory settings
0 to 400 mbar (0 to 6 psi)
0 to 1 bar (0 to 15 psi)
0 to 2 bar (0 to 30 psi)
0 to 4 bar (0 to 60 psi)
0 to 10 bar (0 to 150 psi)
0 to 400 mbar (0 to 6 psi)
0 to 1 bar (0 to 15 psi)
0 to 2 bar (0 to 30 psi)
0 to 4 bar (0 to 60 psi)
0 to 10 bar (0 to 150 psi)
Endress+Hauser
3)
Option
1F
1H
1K
1M
1P
1S
1U
1W
2F
2H
2K
2M
2P
2S
2U
2W
