Description of device parameters
Output 1 (OU1)
Navigation
Description
Options
Factory setting
Output 2 (OU2)
Navigation
Description
Options
Factory setting
Display: HI
IO-Link: HI Max value (maximum indicator)
Navigation
70
Display: EF → Output 1 (OU1)
IO-Link: Parameter → Application → Switch output (OU1) → Output 1 (OU1)
• Hysteresis normally open (HNO):
The switch output is specified as a NO contact with hysteresis properties.
• Hysteresis normally closed (HNC):
The switch output is specified as an NC contact with hysteresis properties.
• Window normally open (FNO):
The switch output is specified as a NO contact with window properties.
• Window normally closed (FNC):
The switch output is specified as an NC contact with window properties.
• Hysteresis normally open (HNO)
• Hysteresis normally closed (HNC)
• Window normally open (FNO)
• Window normally closed (FNC)
Hysteresis normally open (HNO) or as per order specifications
Display: EF → Output 2 (OU2)
IO-Link: Parameter → Application → Switch output (OU2) → Output 2 (OU2)
• Hysteresis normally open (HNO):
The switch output is specified as a NO contact with hysteresis properties.
• Hysteresis normally closed (HNC):
The switch output is specified as an NC contact with hysteresis properties.
• Window normally open (FNO):
The switch output is specified as a NO contact with window properties.
• Window normally closed (FNC):
The switch output is specified as an NC contact with window properties.
• Hysteresis normally open (HNO)
• Hysteresis normally closed (HNC)
• Window normally open (FNO)
• Window normally closed (FNC)
Hysteresis normally closed (HNC) or as per order specifications
Display: EF → I → HI
IO-Link: Parameter → System → Device Management → HI Max value (maximum
indicator)
Ceraphant PTC31B, PTP31B, PTP33B IO-Link
