Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Designation
Switch point value / Upper
value for pressure window,
output 1 (SP1 / FH1)
Switchback point value /
Lower value for pressure
window, output 1 (rP1 /
FL1)
Switching delay time, output
1 (dS1)
Switchback delay time,
output 1 (dR1)
Output 1 (OU1)
Switch point value / Upper
value for pressure window,
output 2 (SP2 / FH2)
Switchback point value /
Lower value for pressure
window, output 2 (rP2 /
FL2)
Switching delay time, output
2 (dS2)
Switchback delay time,
output 2 (dR2)
Output 2 (OU2)
Hi Max value (maximum
indicator)
Lo Min value (minimum
indicator)
Revisioncounter (RVC)
unlocking code (LCK)
locking code (COD)
Measured value display
(DVA)
Display measured value
rotated by 180° (DRO)
Switch display on or off
(DOF)
1) For an explanation of the abbreviations, see the parameter description →  70
Endress+Hauser
ISDU ISDU Size
(dec) (hex) (byte)
77 0x004D 4
78 0x004E 4
79 0x004F 2
80 0x0050 2
81 0x0051 1
89 0x0059 4
90 0x005A 4
91 0x005B 2
92 0x005C 2
93 0x005D 1
82 0x0052 4
83 0x0053 4
84 0x0054 2
94 0x005E 2
95 0x005F 2
96 0x0060 1
97 0x0061 1
98 0x0062 1
Data type Access Default
value
int r/w 9000
int r/w 1000
uint r/w 0
uint r/w 0
uint r/w HNO
int r/w 9500
int r/w 1500
uint r/w 0
uint r/w 0
uint r/w HNC
int r/-
int r/-
uint r/-
uint -/w 0
uint -/w 0
uint r/w 0
uint r/w NO
uint r/w NO
System integration
Value range Offset /
Gradient
in 00.00%, default bar: 0 / 0.001
90.00% kPa: 0 / 0.1
MPa: 0 /
0.0001
psi: 0 / 0.01
in 00.00%, default bar: 0 / 0.001
10.00% kPa: 0 / 0.1
MPa: 0 /
0.0001
psi: 0 / 0.01
in 00.00 sec 0 / 0.01
in 00.00 sec 0 / 0.01
1)
0 ~ HNO ,
1)
1 ~ HNC ,
1)
2 ~ FNO ,
1)
3 ~ FNC
in 00.00%, default bar: 0 / 0.001
95.00% kPa: 0 / 0.1
MPa: 0 /
0.0001
psi: 0 / 0.01
in 00.00%, default bar: 0 / 0.001
15.00% kPa: 0 / 0.1
MPa: 0 /
0.0001
psi: 0 / 0.01
in 00.00 sec 0 / 0.01
in 00.00 sec 0 / 0.01
1)
0 ~ HNO ,
1)
1 ~ HNC ,
1)
2 ~ FNO ,
1)
3 ~ FNC
0~ PV for device with
non-active current
output
1~ PV% only for
devices with active
current output
2~display set switch
point SP
0 ~ NO,
1 ~ YES
0 ~ NO,
1 ~ YES
Data
storage
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
Yes
Yes
Yes
Yes
Yes
