Accessories

16.1

Weld-in adapter

Various weld-in adapters are available for installation in vessels or pipes.
Description
Weld-in adapter M24, d=65, 316L
Weld-in adapter M24, d=65, 316L 3.1 EN10204-3.1
material, inspection certificate
Weld-in adapter G½, 316L
Weld-in adapter G½, 316L 3.1 EN10204-3.1 material,
inspection certificate
Weld-in tool adapter G½, brass
Weld-in adapter G1, 316L, conical metal joint
Weld-in adapter G1, 316L, 3.1, conical metal joint,
EN10204-3.1 material, inspection certificate
Weld-in tool adapter G1, brass
Weld-in adapter G1, 316L, silicone O-ring seal
Weld-in adapter G1, 316L, 3.1, silicone O-ring seal,
EN10204-3.1 material, inspection certificate
If installed horizontally and weld-in adapters with a leakage hole are used, ensure that the
leakage hole is pointing down. This allows leaks to be detected as quickly as possible.
16.2

Process adapter M24

The following process adapters can be ordered for the process connections with order
option X2J and X3J:
Device Description
PTP33B Varivent F DN32 PN40
PTP33B Varivent N DN50 PN40 52023997
PTP33B DIN11851 DN40
PTP33B DIN11851 DN50
PTP33B SMS 1½"
PTP33B Clamp 1½"
PTP33B Clamp 2"
1)
Option
PM
PN
QA
QB
QC
QE
QF
QG
QJ
QK
Order number Order number with inspection certificate 3.1 EN10204
52023996 52024003
52024004
52023999 52024006
52023998 52024005
52026997 52026999
52023994 52024001
52023995 52024002
Accessories
Order number
71041381
71041383
52002643
52010172
52005082
52005087
52010171
52005272
52001051
52011896
