Description of device parameters
Simulation Switch Output (OU2) Simulation output 2 (for devices with 2 switch outputs)
Navigation
Description
Options
Operating Mode (FUNC)
Navigation
Description
Options
Unit changeover (UNI)
Navigation
Description
Options
Factory setting
Zero point configuration (ZRO)
58
Display: DIAG → Simulation Switch Output (OU2)
IO-Link: Diagnosis → Simulation Switch Output (OU2)
Switch output simulation.
If a simulation is active, a warning to this effect is displayed so that it is obvious to the user
that the device is in the simulation mode. A visual warning is indicated on the local display
(C485 - Simulation Active). The simulation must be ended actively via the menu. If the
device is disconnected from the power supply during the simulation and then power is
resupplied afterwards, the simulation mode is not resumed, and instead the device
continues operation in the measuring mode.
• OFF
• OPN (switch output open)
• CLS (switch output closed)
Display: EF → Operating Mode (FUNC)
IO-Link: Parameter → Application → Sensor → Operating Mode (FUNC)
Enables the desired behavior of output 2 (not IO-Link output)
Options:
• OFF
• 4-20 mA (I) ((can only be selected if the device has been ordered with 4-20mA))
• DC-PNP (PNP)
Display: EF → Unit changeover (UNI)
IO-Link: Parameter → Application → Sensor → Unit changeover (UNI)
Select the pressure engineering unit. If a new pressure engineering unit is selected, all
pressure-specific parameters are converted.
• bar
• kPa
• Mpa
• psi
Depends on order specifications.
