Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Endress+Hauser
17.5

Environment

17.5.1 Ambient temperature range
Device Ambient temperature range
PTC31B –20 to +70 °C (–4 to +158 °F)
PTP31B IO-Link: –40 to +70 °C (–40 to +158 °F)
PTP33B (in the range of the temperature limits with restrictions in optical properties, such as display speed
and contrast)
1) Exception: the following cable is designed for an ambient temperature range of
–25 to +70 °C (–13 to +158 °F): Product Configurator order code for "Enclosed accessories" option "RZ".
17.5.2 Storage temperature range
–40 to +85 °C (–40 to +185 °F)
17.5.3 Climate class
Device Climate class
PTC31B Class 3K5
PTP31B
PTP33B
17.5.4 Degree of protection
Device Connection
PTC31B M12 plug
PTP31B
PTP33B
1) Product Configurator order code for "Electrical connection"
17.5.5 Vibration resistance
Test standard
IEC 60068-2-64:2008
17.5.6 Electromagnetic compatibility
• Interference emission as per EN 61326-1 equipment B
• Interference immunity as per EN 61326-1 (industrial environment)
• For intended use, the switch output can switch to the communication mode for 0.2 s in
the event of transient faults.
• Maximum deviation: 1.5% with TD 1:1
For more details, please refer to the Declaration of Conformity.
1)
Note
Air temperature: –5 to +45 °C (+23 to +113 °F),
relative humidity: 4 to 95 %
satisfied according to IEC 721-3-3 (condensation not possible)
Degree of protection
IP65/67 NEMA type 4X enclosure
Vibration resistance
Guaranteed for 5 to 2000Hz: 0.05g
Technical data
1)
Option
M
2 /Hz
