System Architecture

System Architecture
This section describes the processor's configuration on the
ADZS-BF707-BLIP2 board
ADM6315
RESET
JTAG 10
pin 0.05"
24MHz
OSC
24MHz
OSC
Figure 2-1. BLIP2 Board Block Diagram
The ADZS-BF707-BLIP2 board is designed to demonstrate the image
analysis capabilities of the ADSP-BF707 processor. The board houses two
imaging sensors. ASX340AT is a CMOS imaging sensor made by
Aptina/ON Semiconductor. It is placed underneath a M12 lens holder.
2-2
(Figure
SD
32 Mb
connector
Quad Flash
MSI0 SPI2
ADSP-BF707BBCZ-4
UART1 USB
USB Micro
FT232RQ
connector
USB Mini
connector
ADZS-BF707-BLIP2 Board Evaluation System Manual
2-1).
RF Wireless
2GB-LPDDR
connector
DMC0
SPI1
VDD
ADP2230 ADP2370
3.2V
ADP220
ADP195
VIN
DC
