Evaluation License

Click OK. In the Run/Debug settings, click Apply to save and
apply the changes.
10.In the Program(s) to load section, choose the program to load (if
the appropriate program is not already populated) when connect-
ing to the board. If not loading any program upon connection to
the target, do not make any changes.

While connected to the target, there is no way to choose a program
to download. To load a program once connected, terminate the
session and then load the new program.

To delete a configuration, go to the Debug Configurations dialog
box and select the configuration to delete. Click
when asked if you wish to delete the selected launch configuration.
Then Close the dialog box.

To disconnect from the target board, click the terminate button
or choose Run > Terminate.
To delete a session, choose Target > Session > Session List. Select
the session name from the list and click Delete. Click OK.

The default configurations that show up in the CCES Debug Con-
figurations wizard are for JTAG mode debugging only. To use
SWD mode, create a new platform using the Target Configurator.
Evaluation License
When starting CCES for the first time, you are prompted to install a
license with a serial number or to enable evaluation of the product without
a serial number. In the box that contains the EZ-Board is a business card
with a serial number on it. When prompted, choose "I have a serial num-
ber that I would like to activate" and enter the serial number shown on the
card. If the evaluation license is installed but not activated, it allows
1-6 ADZS-BF707-BLIP2 Board Evaluation System Manual
and choose Yes
