Analog Devices ADZS-BF707-BLIP2 Manual page 44

Ref. Qty. Description
12 1 ADP195
DFN65P200X200-7N
13 1 ADM6315 SOT143
14 1 ADP220ACBZ-2828R7
BGA6C50P2X3_100X150
15 1 ADSP-BF707
BGA184C80P14X14_120
0X1200_SCKT
16 1 PWR .65MM CON045
17 2 MOMENTARY SWT024 SW3,SW4
18 2 MOMENTARY SWT024 SW1,SW2
19 1 SD_CONN 8-BIT
CON067
20 1 USB 5PIN CON069
21 1 USB-MICRO 5PIN
HIROSE_ZX62D-AB-5P8
22 1 0.05 10PIN SAM-
TEC_SHF-105-01-L-D-S
M-K
23 1 IDC 4x2 SAMTEC_S-
FMC-104-T1-L-D
24 1 2A FAST 0603
25 1 0 1/4W 5% 1206
26 2 0 1/4W 5% 1206
27 3 1UF 16V 10% 0805 X7R
28 1 0 1/8W 5% 0805
29 2 2.2UH 10% 0805
A-2
Reference
Designator
U5
U3
VR1
U7
P5
J3
P8
P4
P3
J2
F1
R151
R83,R98
C90,C109,C110
R22
L2,L3
ADZS-BF707-BLIP2 Board Evaluation System Manual
Manufacturer Part Number
ANALOG ADP195ACPZ-R7
DEVICES
ANALOG ADM6315-29D2ARTZR7
DEVICES
ANALOG ADP220ACBZ-2828R7
DEVICES
ANALOG ADSP-BF707BBCZ-4
DEVICES
DIGI-KEY CP1-023-ND
PANASONIC EVQ-Q2K03W
PANASONIC EVQ-Q2K03W
MORETHA- MHC-W21-601-LF
NALL
DIGI-KEY H11589CT-ND
DIGI-KEY H11494CT-ND
SAMTEC SHF-105-01-L-D-SM-K-TR
SAMTEC SFMC-104-T1-L-D
BOURNS INC SF-0603F200-2
KOA 0.0ECTRk7372BTTED
KOA 0.0ECTRk7372BTTED
DIGI-KEY 399-1284-2-ND
VISHAY CRCW08050000Z0EA
DIGI-KEY 490-1119-2-ND
