User Manual - DPM3-P Series Digital Panel Meters

Wiring Terminals

CN4
4
5
6
CN1
1 2
CN1
AC Supply DC Supply
1 Line 1 VDC
2 Neutral 2 VDC
Polarity insensitive for
DC power
CN3
Logic Functions
1 Common
2 Reset Process
3 Reset Totalizer
4 Hold
Connector CN1
Wire cross section 0.08 to 2.5mm²
(28 to 12 AWG)
Strip length 8 to 9mm
Wago 231-
Manufacturer
202/026-000
Insertion tool
Cage clamp or screwdriver
connection with 0.5 mm x
3.0 mm blade
CN2 and CN3 Terminals
Refer to the instructions in this manual to preserve safety protections.
8
CN5
CN6
1
1
2
3
2
CN2 CN3
1 2 3 4 5 6 7 8 1 2 3 4
CN2
Signal Inputs
1 Not used
2 (+) 20V Excitation
(+) 8.2 V Excitation for NAMUR
3
sensors
4 (-) Common excitation / signal
5 Signal B input
6 Signal A input
7 Not used
8 High voltage input (300VAC max.)
Terminals
CN2
0.08 to 0.5mm² 0.08 to 0.5mm²
(28 to 20 AWG) (28 to 20 AWG)
5 to 6mm 5 to 6mm
Wago 733-108 Wago 733-104 Wago 231-
Insertion tool Insertion tool
or screwdriver or screwdriver
with 0.3 mm x with 0.3 mm x
1.8 mm blade 1.8 mm blade
Insertion Tool (included with meter)
Insert wires into the proper terminal
while using the insertion tool to open
the clip inside the connector. Release
the insertion tool to fix wire to the
terminal.
DPM3-P User Manual, 1st Edition
DPM3-P-A2R-H & DPM3-P-A2R-L
CN3 CN4 & CN5
0.08 to 2.5mm² 0.08 to 2.5mm²
(28 to 12 AWG) (28 to 12 AWG)
8 to 9mm 8 to 9mm
Wago 231-
303/026-000 302/026-000
Insertion tool Insertion tool
or screwdriver or screwdriver
with 0.5 mm x with 0.5 mm x
3.0 mm blade 3.0 mm blade
CN1, CN4, CN5
and CN6 Terminals
CN4
Relay 2 SPDT Relay 1 SPDT
4 NO2 1
5 CM2 2
6 NC2 3
NO: Normally open, CM: Common,
NC: Normally closed
Analog Output
1
2
CN6
Insertion Tool (included with meter)
Insert wires into the proper terminal
while using the insertion tool to open
the clip inside the connector. Release
the insertion tool to fix wire to the
terminal.
CN5
NO1
CM1
NC1
CN6
(-) 4-20mA
(+) 4-20mA
