User Manual - DPM3-P Series Digital Panel Meters

Counter Mode Programming Diagram

ModE
Count
uP
InA
-Pro-

Counter Configuration

Inputs

The counter has two inputs, the A input receives the pulses to count, and the B input serves
to inhibit the count or to change the count direction, except in case of bidirectional counter
IndEP where the second input is also used to count pulses.

Pulse Measurement

The pulses applied to the input are detected on the rising edge, except for type 5 (NPN) and
type 7 (Switched contact) that detect the falling edge, and immediately update the value of the
counter and the status of the alarms if existed.
The display refreshes every 100 ms.
In a power loss, the meter saves the count value reached internally.
14
CHron
do
IndEP
InAB
DPM3-P User Manual, 1st Edition
FrEC
updo
dIrEC
Programming Keys
ENTER: Vertical displacement.
UP: Changes active digit.
SHIFT: Horizontal displacement.
tACH
PHASE
