Device Description

The ProSense DPM3-P series offers a simple, feature packed digital display for counter,
chronometer, frequency, tachometer, rate, and pulse width modulated (PWM) applications.
The DPM3-P has a 5-digit, 14mm character height, tri-color red, green or amber LED,
accepts input from AC voltage, magnetic sensors, NPN/PNP sensors, NAMUR sensors,
TTL/24V encoders, or switched contacts, and provides selectable sensor excitation voltages.
Models are available with two SPDT relay outputs that can be set to activate on an increasing
or decreasing input signal with hysteresis or time delay operation in tachometer, rate, and
frequency modes as well as pulsed or latched operation in counter and chronometer modes.
Additionally the display color can be set to change on relay operation. Models are also
available with a 4-20mA analog output. The meter is powered from an external AC or DC
power supply. The 1/8 DIN housing is easy to install in a panel and the meter face has an
IP65 rating. Configuration parameters can be totally or selectively locked out to prevent
unauthorized or accidental changes to the meter's operation. Other features include memory
and reset of minimum (valley) and maximum (peak) display values, start/stop in chronometer
mode or stop in counter mode, and display brightness adjustment. ProSense digital panel
meters are backed by a 3 year warranty.
• 96 x 48mm 1/8 DIN
• 5 digit (-99999 to 99999) tri-color (red, green, amber) LED display
• Selectable decimal point
• Counter/Chronometer/Frequency/Tachometer (RPM/Rate/PWM) modes
• AC or DC powered
• Optional 4-20mA analog output
• Optional (2) Form C SPDT
• Total or selective configuration lock out
• Programmable functions include:
• Display brightness adjustment
• 3 year warranty
6
- AC voltage
- Magnetic sensor
- NAMUR sensor
- NPN/PNP sensor
- TTL/24V encoder
- Switched contact
Activation on increasing or decreasing input signal
Hysteresis or time delay operation (frequency and tach modes)
Pulsed or latch operation (counter and chronometer modes)
Display color change on relay operation
Minimum (valley) and maximum (peak) value memory
Minimum (valley) and maximum (peak) value reset
Start/Stop in chronometer mode or Stop in counter mode
