Variables

The main variable of the counter is the PROCESS variable that is the number of pulses
registered from the last RESET operation.
If the totalizer option is enabled, there are PROC and TOTAL variables.
The TOTAL variable counts the total number of pulses received, independently of the reset
operations that may take place in the process display.

Display

Process: The limits of the display are 99999 and -99999. When the meter exceeds 99999, it
shows oVEr, and when it falls below -99999, it shows -oVEr.
The positive sign is indicated by the red LED Up arrow located on the left side of the display
and the negative sign is indicated by the red LED Down arrow located on the left side of the
display.
The decimal point can be located in any of the digits of the display.
Total: The limits are 99999999 and -9999999. When the meter exceeds these limits the
display shows the indications oVEr or -oVEr.
The negative sign, when the value has less than five digits, appears in the most significant digit
of the display. The negative sign is indicated by the MIN LED.
When the total value has more than five digits, the display alternates the 4 digits high order
part and the 4 digits low order part (the letters 'H' and 'L' in the auxiliary digit indicate which
part is on display.
The decimal point can be located in any of the digits of the low part.
